I keep the majority of my operators on a hidden layer called Operators. However it’s a pain to turn on the layer when I need it on. In times past I’d either go to the layers, select operator, turn it on, or I’d go to an “all on” layer combination, or a special layer combination that was a “3D + operators,” or I’d select a slab, change it to the
I’ve set the keyboard shortcut for the Quick Layers palette to ‘control + X’. The filtering capabilities of this little palette are huge and easy to use. I am always isolating layers to do quick moves. When working on a complex model (or drawing), very often the answer is to turn off layers, make the changes, and turn layers back on. The Show/Hide toggle is great for sifting through what
I’m excited about version 14. I started using ArchiCAD on version 9, dabbled in 8.1, 10, 12, and 13, and have been using v11 since it was released. While working on my first project in v11 back in 2007, I discovered the joys of the complex profile in ArchiCAD. If you use ArchiCAD, but don’t use this tool to its breaking point…finish reading and then go spend as much time
We all have bad habits in ArchiCAD. Some of this is from how we were taught and some from the version we learned on. As the program evolves, we need to reevaluate how we work. Do we still need to hold down shift? Is it time to get used to the tracker? Are we still hanging on to old key commands from v8.1? Some are worth keeping. I want to
I recently attended the usergroup for another BIM software. And I’m damn proud of our local ArchiCAD usergroup. Our mailing list is about a 1/6th the size of theirs, but they only had about double our usual turn out. Good for us! My favorite comment from the evening was “If you lose your job as a [other BIM software] technician, you can get a job as a database programmer!” What?
Whether you’re using the the coordinate box or the tracker, there are a lot of ways to write a number. Some are easier than others. A quick rule of thumb is that ArchiCAD recognizes fractions as inches, whole numbers and decimals as feet. So… a couple of ways to input three and a half inches: .2916667′ .2916667 0-3.5″ 0-3.5 3.5″ 3 1/2″ 3 1/2 3.5/1 3.5/ 7/2″ 7/2
Here’s a quick recap of MNAUG #7. David Wilson from Charles Stinson Architects introduced all of us to Artlantis. He did a great job of walking us through a project from ArchiCAD through Artlantis to final tweaking in Photoshop. If anyone wants to see some of the images he presented, contact me. I was impressed with a lot of what David showed us, so I’ll only mention a few things.
Take a few minutes and check out the techniques mentioned on this post as well as this one on the ArchiCAD-Talk forum. I highly recommend setting up a keyboard shortcut for the command mentioned in the second post. I have set mine to ‘[‘. It’s fast, easy, and I can’t believe I lived without it all these years. I’ll talk more about my tangential comments within that second thread next week.
Below is an excerpt from a draft of a document I’m putting together for my role as CAD / BIM Manager at SALA Architects: Competencies: Outside of the office standards, users will not learn or use the program in an identical manner. As a result, tiers of users are differentiated by having competency in a certain quantity of skills within the program, rather than specific requirements. The intent is that
